Nationwide Solar & Battery Installations Across the UK
We provide professional solar and battery storage installations nationwide across most areas of the UK. Every system is fully certified and installed by qualified engineers, giving you peace of mind and long-term reliability.
Sunsynk 10-12kw Data Sheet
Sunsynk 16kW Data Sheet
Fogstar Battery stack Datasheet
Fogstar Battery stack Installation manual
Home Backup:
Home backup is available by utilising the Fox EPS Box together with the Gateway / EPS wiring. To add this to your order, following payment of the deposit, notify our team along with the requested information so the cabling route can be checked and can be added to your order without VAT.
Sunsynk 10-12kW Single-Phase Hybrid Inverter
The SunSynk 10kW Inverter represents the next generation of super hybrid solar inverters, delivering exceptional performance, flexibility and reliability for home and commercial energy systems.
With a powerful 15,000 W MPPT input and a rated 10 kW AC output, this single-phase inverter generates more than enough energy even during the winter months to offset overall electricity usage.
Key Features
-
Dual MPPT design for optimal solar energy harvesting
-
Compatible with Lithium-ion and Lead-Acid batteries
-
IP65 weatherproof rating for indoor or outdoor installation
-
Anti-islanding protection for grid safety compliance
-
Fully programmable power export control
-
Automatic switching between Grid-Tied and Off-Grid operation
-
Parallel capability — connect up to 16 units (with same firmware)
-
Maximum charging/discharging current: 220 A
-
Supports energy storage from diesel generators
-
Essential and Non-Essential Loads outputs for smart energy management
-
5-year standard warranty
Sunsynk MAX 16kW Single-Phase Hybrid Inverter
Overview
The Sunsynk MAX 16kW is the largest single-phase hybrid inverter on the market, designed for off-grid, grid support, backup, and self-consumption solar PV systems. This low-voltage (48V) inverter is highly versatile and can also be used in three-phase or single-phase parallel configurations for larger installations.
Key Features
-
Flexible Parallel Operation:
-
Triple MPPT Inputs: Allows for flexible PV array design and maximises energy harvest.
-
Programmable Operation Modes: On-grid, off-grid, and UPS functionality.
-
IP65 Rated: Suitable for indoor and outdoor installations.
-
Wi-Fi Enabled: Built-in dongle for remote monitoring via the Sunsynk Cloud.
-
Battery Compatibility: Works with Hubble Lithium, Pylontech LV, Freedomwon, Kodak (BL3.6), and other leading brands.
-
Integrated DC Switch: Simplifies installation and improves safety.
-
High Efficiency: Euro efficiency up to 97.6%.
-
5-Year Warranty
The Fogstar Energy Modular Battery Stack (FE51.2-48.3) is a high-capacity, low-voltage (51.2V) LiFePO₄ energy storage system designed for residential, commercial and light industrial applications.
Built from 1-4 X 16.1kWh battery modules, and managed by a single top-mounted control unit that operates the system as one fully integrated solution.
With the ability to scale up to 1.23MWh, IP65 protection, integrated heating and built-in fire suppression, this system is engineered for reliable performance in demanding UK environments.
System Overview
Each stack consists of:
• 16.1kWh LiFePO₄ battery modules
• Integrated top-mounted control unit
• Heavy-duty base plate structure
• Built-in 350A isolation breaker
Once assembled, the control unit manages all modules as one unified battery system — simplifying commissioning, inverter communication, monitoring and servicing.
The modular architecture allows additional stacks to be added at any time, making this solution ideal for phased commercial installs or growing energy demand.
Advanced Integrated BMS
A high-performance Battery Management System delivers:
• Precise charge & discharge control
• Full protection against over/under voltage & temperature
• Support for high-power inverter systems
• Long-term reliability and system stability
Fully Scalable Architecture
• Multiple stacks connected in parallel
• Scales up to 1.23MWh total capacity
Perfect for commercial properties, agricultural sites, workshops, warehouses and large residential installs.
IP65-Rated Construction
A robust, sealed enclosure protects against dust and moisture, allowing:
• Indoor installation
• Plant room installation
• Outdoor installation (where suitable)
Built for real-world environments.
Integrated Fire Suppression
Heat-activated aerosol fire suppression system provides:
• Automatic internal protection
• No external maintenance requirements
• Enhanced site safety compliance
Cold-Weather Ready (Down to –15°C)
Integrated battery heating enables:
• Safe low-temperature charging
• Reliable winter operation
• Installation in unheated plant rooms and outbuildings
Operating conditions:
• Charge: 0–45°C (with heating enabled)
• Discharge: –20–45°C
JK 2A Active Cell Balancing
Continuous active balancing improves:
• Cell voltage equalisation
• System efficiency
• Long-term lifespan
• Performance stability under load
High Output Performance
• 51.2V (48V nominal) low-voltage system
• 300A maximum charge & discharge current
• Designed to support high-demand inverters
• Ideal for backup, peak shaving & off-grid applications
Built-In 350A Breaker
Integrated breaker allows full system isolation for:
• Maintenance
• Fault conditions
• Emergency shutdown
Warranty & Support
• 6-Year Manufacturer Warranty
• 10 Years UK-Based Customer Support
